|Wadkin CC2000 Fixed Head, Moving Table Osai 10/110 Control 8 Stationary rotary magazine|
Fixed head moving table CNC Router. Machine has a single router spindle covering the full 670 x 970 bed.
Latest Osai 10/110 CNC controller fitted in a mobile trolley. High performance DC servo drives and controllers fitted.
X axis travel 920
Y axis travel 620mm
Z axis travel 180mm
Table size 670 x 970
Machine fitted with fixture table made from phenolic
Feed rates (optional 12m / min x and Y axes)
X axis 0-12m/min
Y axis 0-12m/min
Y, Y axes 12m/min
Machine fitted with a new Osai 10/110 CNC. Floppy disk drive fitted and 10/100 Ethernet installed. The Osai gives high performance in both contouring and memory size. It is also fully supported now and in the future by OSAI UK and ourselves.
- 800 megabytes program storage – Hard drive
- 133mhz CPU ,8 Mbytes Ram
- 10.4″ tft colour operator console keyboard interface.
- FDU Interface RS232 port RS232 / 422 / 485 port
- 3 encoder channels 4 d/A converters 1 Ad Converter (12 bits)
- 48 local inputs (10ma) 24 local output (300ma)
- 3.5″ floppy disc drive and Ethernet interface
HSD 7.5 kW router head with auto toolchange function and 8 station rotary magazine
Extraction is via a simple extraction hood. ISO 30 toolholders , max collet size is 20mm. Larger sizes are available with bigger tool holders
